1775151-3
RoHS
/
Package /
Category Connectors, Interconnects / Pluggable Connectors
Description
Pluggable Connector
PDF
/
Inventory: 8718
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Current Rating 1.5A
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.591 inch
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Total Number of Contacts 22
Pitch 1.27mm
Voltage - Rated DC 12V
Subcategory Headers and Edge Type Connectors
Gender Female
Number of Rows 1
Color Black
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Number of Positions 22
Connector Type SATA
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Board Lock
Packaging Tape & Reel (TR)
Contact Pattern RECTANGULAR
Durability 500 Cycles
Connector Style Receptacle
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Insulation Resistance 1GOhm
Contact Resistance 45mOhm
Contact Style BELLOWED TYPE
Body Depth 0.505 inch
Body Breadth 0.175 inch
Physical
Housing Material Polymer
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Material Bronze
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
