MECT-115-01-M-D-RA1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
Conn SFP+ Card Edge SKT 30 POS 0.8mm Solder RA SMD Tube
PDF
/
Buying Options
Total Price: USD $3.95
Unit Price: USD $3.9512
≥1 USD $3.9512
≥10 USD $3.2208
≥100 USD $2.7368
≥500 USD $2.428818
≥1000 USD $2.277
Inventory: 77
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Plating Thickness 15μin
Contact Finish Thickness 15.0μin 0.38μm
Technical
Contact Pattern RECTANGULAR
Connector Style Receptacle
Max Voltage Rating (AC) 265V
Contact Style SINGLE PRONG
Rated Current (Signal) 2A
Housing Color Black
Contact Gender MALE
Number Of PCB Rows 1
Reliability COMMERCIAL
Contact Finish Gold
Orientation Right Angle
Total Number of Contacts 30
Pitch 800μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 30
Connector Type SFP+
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
JESD-609 Code e3
Series MECT
Published 2013
Packaging Tube
Physical
Housing Material Polymer
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Material Bronze
Supply Chain
Factory Lead Time 3 Weeks
