75586-0009
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
CONN MINI SAS RCP 26P SLD RA SMD
PDF
/
Buying Options
Total Price: USD $27.36
Unit Price: USD $27.3562
≥1 USD $27.3562
≥10 USD $22.44565
≥100 USD $21.74455
≥500 USD $21.04345
≥1000 USD $20.3414
Inventory: 110
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Technical
Halogen Free Low Halogen
Contact Pattern STAGGERED
Max Voltage Rating (DC) 3.03kV
Connector Style Receptacle
Dielectric Withstanding Voltage 300VAC V
Polarization Key POLARIZED HOUSING
Body/Shell Style PLUG
Insulation Resistance 1000000000Ohm
Contact Resistance 30mOhm
Contact Style BELLOWED TYPE
Rated Current (Signal) 0.5A
Body Depth 0.453 inch
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender FEMALE
PCB Contact Pattern STAGGERED
Number of Contacts 26
Lead Pitch 800μm
Number Of PCB Rows 2
Reliability COMMERCIAL
Voltage - Rated AC 30V
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Current Rating 500mA
Shielding Unshielded
Orientation Right Angle
Pitch 800μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.30
Additional Feature ROHS,ELV COMPLIANT & REEL PKG.
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 80°C
Connector Type SAS, Mini
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
JESD-609 Code e3
Series iPass PCI Express 75586
Published 2011
Packaging Cut Tape (CT)
Physical
Housing Material Thermoplastic
Shell Material GLASS FILLED POLYETHYLENE
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
