5010542670
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
CONN PLUG 26POS SLD R/A SMD
PDF
/
Inventory: 6695
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Plating Thickness 4μin
Technical
Withdrawl Force-Min .2224 N
Insertion Force-Max 1.529 N
Durability 5000 Cycles
Connector Style Plug
Dielectric Withstanding Voltage 200VAC V
Polarization Key POLARIZED KEY
Insulation Resistance 1000000000Ohm
Contact Resistance 50mOhm
Contact Style USB, SER A FLAT
Rated Current (Signal) 0.5A
Body Depth 0.333 inch
Empty Shell NO
UL Flammability Code 94V-0
Operating Temperature (Min) -20°C
Contact Gender MALE
Body Breadth 0.152 inch
Operating Temperature (Max) 60°C
PCB Contact Pattern STAGGERED
Number Of PCB Rows 2
Body Length or Diameter 0.386 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Terminal Pitch 0.508mm
Total Number of Contacts 26
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Telecom and Datacom Connectors
HTS Code 8536.69.40.30
Additional Feature ROHS COMPLIANT,TAPE/REEL PKG
Number of Positions 26
Connector Type Cradlecon
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Shielded, Solder Retention
Series Cradlecon 501054
Published 2012
Packaging Tape & Reel (TR)
Physical
Mounting Option 2 FRICTION LOCK
Board Mounting Option PEG
Mounting Option 1 LOCKING
Shell Material STAINLESS STEEL
Insulation Material GLASS FILLED PLASTIC
Mounting Type Surface Mount, Right Angle
Contact Material NOT SPECIFIED
