5010142071
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
CONN PLUG 20POS SLD R/A SMD
PDF
/
Inventory: 7334
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Shell Material STAINLESS STEEL
Housing Material Thermoplastic
Technical
Packaging Tape & Reel (TR)
Published 2012
Series Cradlecon 501014
Feature Board Guide, Shielded
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Cradlecon
Number of Positions 20
Max Operating Temperature 60°C
Min Operating Temperature -20°C
Color Black
Subcategory Telecom and Datacom Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 500μm
Total Number of Contacts 20
Orientation Right Angle
Depth 8.45mm
Current Rating 500mA
Shell Finish TIN OVER NICKEL
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Voltage - Rated AC 30V
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern STAGGERED
Contact Gender MALE
UL Flammability Code 94V-0
Empty Shell NO
Rated Current (Signal) 0.5A
Contact Style USB, SER A FLAT
Contact Resistance 50mOhm
Max Voltage Rating (AC) 30V
Polarization Key POLARIZED KEY
Connector Style Plug
Number of Ports 1
Durability 5000 Cycles
Dimensions
Length 8.3mm
Contact Finish Thickness 3.94μin 0.10μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
