1717222003

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Pluggable Connectors
Description Pluggable Connector
PDF
/
Inventory: 4055
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Technical

Insulator Color BLACK
Withdrawl Force-Min .5004 N
Insertion Force-Max 39.1424 N
Durability 100 Cycles
Connector Style Receptacle with Cage, Ganged (2x2)
Body/Shell Style PLUG
Mating Contact Pitch 0.031 inch
Rated Current (Signal) 0.5A
Operating Temperature (Min) -40°C
Contact Gender MALE
Operating Temperature (Max) 85°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.30
Number of Positions 152 (38 x 4)
Connector Type ZQSFP+
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide, EMI Shielded, Light Pipe
Series 171722
Published 2013
Packaging Tray

Physical

Mounting Option 1 LOCKING
Insulation Material THERMOPLASTIC
Mounting Type Through Hole, Right Angle
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 15 Weeks
