1703820003
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
Pluggable Connector
PDF
/
Inventory: 6853
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Technical
Insulator Color BLACK
Contact Pattern RECTANGULAR
Durability 250 Cycles
Connector Style Receptacle
Mating Contact Pitch 0.031 inch
Contact Resistance 14mOhm
Contact Style BELLOWED TYPE
Body Depth 0.31 inch
Operating Temperature (Min) -40°C
Body Breadth 0.211 inch
Operating Temperature (Max) 85°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Body Length or Diameter 0.433 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Reach Compliance Code compliant
Terminal Pitch 0.7874mm
Total Number of Contacts 20
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Positions 20
Connector Type zSFP+
ECCN Code EAR99
Termination Solder
Part Status Active
Feature Board Guide
Series 170382
Packaging Tape & Reel (TR)
Physical
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED THERMOPLASTIC
Mounting Type Surface Mount, Right Angle
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 27 Weeks
