1703820002
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
Conn SFP F 20 POS 0.8mm Solder RA SMD 20 Terminal 1 Port Reel
PDF
/
Buying Options
Total Price: USD $3.54
Unit Price: USD $3.5376
≥1 USD $3.5376
≥10 USD $3.11608
≥100 USD $2.478344
Inventory: 305
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Length 11mm
Technical
Halogen Free Low Halogen
Max Voltage Rating (DC) 120.12kV
Number of Ports 1
Connector Style Receptacle
Max Voltage Rating (AC) 120V
ELV Compliant
Body/Shell Style PLUG
Contact Style TELCOM, MODULAR
Rated Current (Signal) 0.5A
Housing Color Black
Contact Gender FEMALE
Number of Contacts 20
Reliability COMMERCIAL
Voltage - Rated AC 120V
Contact Finish Gold
Reference Standard UL
Current Rating 500mA
Depth 7.87mm
Orientation Right Angle
Pitch 800μm
Subcategory Telecom and Datacom Connectors
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Connector Type zSFP+
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
Series 170382
Published 2012
Packaging Cut Tape (CT)
Physical
Housing Material Polycarbonate
Material Brass
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Material Brass, Bronze
Supply Chain
Factory Lead Time 27 Weeks
