0783950001
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
CONN MICRO SAS RCPT 25P SLD RA
PDF
/
Inventory: 8938
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Surface Mount, Right Angle
Insulation Material GLASS FILLED LIQUID CRYSTAL POLYMER
Shell Material POLYETHYLENE
Mounting Option 1 LOCKING
Board Mounting Option SPLIT BOARD LOCK
Technical
Packaging Tray
Series 78395
Feature Board Guide, Board Lock
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type SAS, Micro
Number of Positions 25
Additional Feature POLARIZED
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Total Number of Contacts 25
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.364 inch
Operating Temperature (Max) 55°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.246 inch
Contact Gender FEMALE
UL Flammability Code 94V-0
Empty Shell NO
Body Depth 0.571 inch
Rated Current (Signal) 1.5A
Contact Style SQ PIN-SKT
Contact Resistance 45mOhm
Insulation Resistance 1000000000Ohm
Dielectric Withstanding Voltage 500VAC V
Connector Style Receptacle
Durability 500 Cycles
Insertion Force-Max .8062 N
Withdrawl Force-Min .1112 N
Insulator Color BLACK
Contact Arrangement S16P9
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Compliance
RoHS Status ROHS3 Compliant
