0757840210
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
Conn I-Pass F 50 POS 0.8mm Solder ST SMD 50 Terminal 1 Port Embossed T/R
PDF
/
Inventory: 7072
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Length 23.4mm
Technical
Number of Ports 1
Connector Style Receptacle
Max Voltage Rating (AC) 30V
Empty Shell NO
Housing Color Black
UL Flammability Code 94V-0
Number of Contacts 50
Contact Finish Gold
Depth 12.12mm
Orientation Vertical
Pitch 800μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature IPASS, POLARIZED
Gender Female
Min Operating Temperature -40°C
Max Operating Temperature 80°C
Connector Type SAS, Mini
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
Series iPass 75784
Packaging Tape & Reel (TR)
Physical
Housing Material Thermoplastic
Shell Material POLYETHYLENE
Mounting Type Surface Mount
Mount Surface Mount
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 13 Weeks
