0757840141
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
High Speed / Modular Connectors i-Pass Vert Assy 36c kt Plt 2 T/H2.79 Lt
PDF
/
Inventory: 4151
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 17.8mm
Technical
Number of Ports 1
Connector Style Receptacle
Max Voltage Rating (AC) 30V
Empty Shell NO
Housing Color Black
UL Flammability Code 94V-0
Number of Contacts 36
Contact Finish Gold
Current Rating 500mA
Depth 12.12mm
Orientation Vertical
Pitch 800μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature IPASS, POLARIZED
Gender Female
Number of Rows 2
Min Operating Temperature -40°C
Max Operating Temperature 80°C
Connector Type SAS, Mini
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
Series iPass 75784
Packaging Tape & Reel (TR)
Physical
Housing Material Thermoplastic
Shell Material POLYETHYLENE
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
