0757345003
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
Conn SFP F 200 POS 1.6mm Press Fit RA Thru-Hole 200 Terminal 10 Port Tray
PDF
/
Inventory: 4913
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Contact Material Brass, Tin
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Thermoplastic
Technical
Packaging Tray
Series 75734
JESD-609 Code e3
Feature Board Guide, EMI Shielded, Light Pipe
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type SFP
Number of Positions 200 (20 x 10)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8536.69.40.30
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 800μm
Total Number of Contacts 200
Orientation Right Angle
Depth 63.25mm
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color Black
Empty Shell NO
Number of Circuits 200
Connector Style Receptacle with Cage, Ganged (2x5)
Number of Ports 10
Dimensions
Length 71.5mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
