0754775001

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Pluggable Connectors
Description Conn SFP F 240 POS 1.6mm Press Fit RA Thru-Hole 240 Terminal 12 Port Tray
PDF
/
Buying Options
Total Price: USD $102.18
Unit Price: USD $102.182388
≥1 USD $102.182388
≥10 USD $96.398475
≥100 USD $90.941952
≥500 USD $85.7943
≥1000 USD $80.938021
Inventory: 6732
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Technical

Insulator Color BLACK
Durability 100 Cycles
Connector Style Receptacle with Cage, Ganged (2x6)
Mating Contact Pitch 0.031 inch
Rated Current (Signal) 0.5A
Operating Temperature (Min) -40°C
Contact Gender FEMALE
Operating Temperature (Max) 85°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 240
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.30
Number of Rows 2
Number of Positions 240 (20 x 12)
Connector Type SFP
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide, EMI Shielded
JESD-609 Code e3
Series 75477
Packaging Tray

Physical

Board Mounting Option COMPLIANT BOARDLOCK
Mounting Option 1 LOCKING
Insulation Material THERMOPLASTIC
Mounting Type Through Hole, Right Angle
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 16 Weeks
