0747030407

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Pluggable Connectors
Description Conn HSSDC2 RCP 7 POS 1.27mm Solder RA SMD 7 Terminal 1 Port Embossed T/R
PDF
/
Inventory: 3320
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 5.00μin 0.127μm
Length 14.1mm

Technical

Max Voltage Rating (DC) 30V
Number of Ports 1
Connector Style Receptacle
Number of Circuits 7
Housing Color Natural
Contact Finish Gold
Current Rating 500mA
Number of Positions Loaded 7
Depth 51.56mm
Orientation Right Angle
Pitch 1.27mm
Number of Rows 1
Min Operating Temperature -10°C
Max Operating Temperature 60°C
Number of Positions 7
Connector Type HSSDC2
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Shielded
Series 74703
Packaging Tape & Reel (TR)

Physical

Housing Material Polymer
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold
Contact Material Nickel
