0678008001
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
Conn SATA HDR 7 POS Solder ST Thru-Hole 7 Terminal 1 Port Tray
PDF
/
Inventory: 5506
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyester
Technical
Packaging Tray
Series 67800
Feature Board Guide, Friction Lock
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type SATA
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Number of Rows 1
Additional Feature POLARIZED, SHROUDED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Orientation Vertical
Depth 6.45mm
Current Rating 1.5A
Contact Finish Gold
Number of Contacts 7
Contact Gender MALE
UL Flammability Code 94V-0
Empty Shell NO
Connector Style Header, Shrouded
Dimensions
Length 16.9mm
Contact Finish Thickness Flash
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
