0674921420
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Connectors, Interconnects / Pluggable Connectors
Description
Conn SATA RCP 15Power/7Signal POS 1.27mm Solder RA SMD 22 Terminal 1 Port Tray
PDF
/
Inventory: 1607
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness Flash
Length 40.43mm
Technical
Max Voltage Rating (DC) 15V
Number of Ports 1
Connector Style Receptacle
Number of Circuits 22
Contact Finish Gold
Current Rating 1.5A
Depth 12.87mm
Orientation Right Angle
Pitch 1.27mm
Number of Rows 1
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Number of Positions 22
Connector Type SATA
Termination Solder
Number of Terminations 22
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock, Mating Guide
Series 67492
Packaging Tray
Physical
Housing Material Thermoplastic
Package / Case SMD/SMT
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Plating Gold
Supply Chain
Factory Lead Time 19 Weeks
