0674921221
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Connectors, Interconnects / Pluggable Connectors
Description
Conn SATA RCP 15Power/7Signal POS 1.27mm Solder RA SMD 22 Terminal 1 Port T/R
PDF
/
Inventory: 1547
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Package / Case SMD/SMT
Housing Material Thermoplastic
Technical
Packaging Tape & Reel (TR)
Series 67492
Feature Board Lock, Mating Guide
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 22
Termination Solder
Connector Type SATA
Number of Positions 22
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Black
Number of Rows 1
Gender Female
Pitch 1.27mm
Orientation Right Angle
Depth 12.87mm
Current Rating 1.5A
Contact Finish Gold
Number of Circuits 22
Connector Style Receptacle
Number of Ports 1
Max Voltage Rating (DC) 15V
Dimensions
Length 40.43mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
