0674913012
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
Conn SATA PL 7 POS Solder ST Thru-Hole 7 Terminal 1 Port Tray
PDF
/
Inventory: 2534
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Length 16mm
Technical
Max Voltage Rating (DC) 15V
Number of Ports 1
Connector Style Header
Empty Shell NO
Contact Gender MALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Current Rating 1.5A
Depth 4mm
Orientation Vertical
Total Number of Contacts 7
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature POLARIZED
Color Black
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Positions 7
Connector Type SATA
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series 67491
Packaging Tray
Physical
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
