0473062001
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
Conn SATA HDR 7 POS 1.27mm Solder ST SMD 7 Terminal 1 Port Embossed T/R
PDF
/
Inventory: 2983
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness Flash
Length 16.9mm
Technical
Number of Ports 1
Connector Style Header, Shrouded
Number of Circuits 22
Contact Finish Gold
Current Rating 1.5A
Depth 6.45mm
Orientation Right Angle
Pitch 1.27mm
Number of Rows 1
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Number of Positions 7
Connector Type SATA
Termination Solder
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide
Series 47306
Packaging Tape & Reel (TR)
Physical
Housing Material Thermoplastic
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Contact Material Brass
Supply Chain
Factory Lead Time 15 Weeks
