SATA-E-PR-SMT-K
RoHS
/
Package /
Category Connectors, Interconnects / Pluggable Connectors
Description
Pluggable Connector
PDF
/
Inventory: 5408
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Contact Finish Thickness Flash
Technical
Insulator Color BLACK
Contact Pattern RECTANGULAR
Connector Style Header, Shrouded
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Body/Shell Style PLUG
Insulation Resistance 1000000000Ohm
Contact Resistance 30mOhm
Rated Current (Signal) 1.5A
Body Depth 0.48 inch
Operating Temperature (Min) -55°C
Contact Gender MALE
Body Breadth 0.273 inch
Operating Temperature (Max) 85°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Body Length or Diameter 1.26 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Number of Conductors ONE
Reach Compliance Code compliant
Terminal Pitch 1.27mm
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Number of Positions 14
Connector Type SATA
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Board Lock
Packaging Bulk
Physical
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED THERMOPLASTIC
Mounting Type Surface Mount, Right Angle
Contact Material PHOSPHOR BRONZE
