8C26-12000

3M
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Pluggable Connectors
Description Pluggable Connector
PDF
/
Inventory: 9069
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Connector Style Cage
Body/Shell Style RECEPTACLE
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender FEMALE
Shell Finish NICKEL
Total Number of Contacts 26
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating GOLD (30) OVER NICKEL (50)
Connector Type SAS, Mini
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature EMI Shielded
JESD-609 Code e3
Series 8C26
Packaging Tray

Physical

Shell Material ZINC ALLOY
Insulation Material POLYETHYLENE
Number of Pins 26
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material COPPER ALLOY

Supply Chain

Factory Lead Time 10 Weeks
