5607-4200-SH
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Pluggable Connectors
Description
CONN PLUG SATA 7POS SMT R/A GOLD
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 6467
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Contact Finish Thickness Flash
Length 17.46mm
Technical
Number of Ports 1
Connector Style Plug
Max Current Rating 1.5A
Insulation Resistance 1GOhm
Housing Color Black
Number of Contacts 7
Lead Pitch 1.27mm
Contact Finish Gold
Current Rating 1.5A
Depth 11.5mm
Orientation Right Angle
Pitch 1.27mm
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 7
Connector Type SATA
Termination Solder
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock
Series 5607
Published 2008
Packaging Tube
Physical
Housing Material Thermoplastic
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Plating Gold
Supply Chain
Factory Lead Time 8 Weeks
