566AAA001115BBGR
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Pin Configurable/Selectable Oscillators
Description
ROHS3Compliant Enable/Disable Crystal e4 oscillating selection -40C~85C 2.5V 3.3V 170mA 0.197Lx0.126W 5.00mmx3.20mm
PDF
/
Inventory: 9797
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 0.052 1.33mm
Technical
Frequency - Output 1 1.412135GHz 2.304GHz
Current - Supply (Max) 170mA
Base Resonator Crystal
Function Enable/Disable
Output LVPECL
Frequency Stability ±20ppm
Voltage - Supply 2.5V 3.3V
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Type VCXO
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Series Ultra? Si566
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case 6-SMD, No Lead
Supply Chain
Factory Lead Time 6 Weeks
