564BAED002104BBG
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD, No Lead
Category Crystals, Oscillators, Resonators / Pin Configurable/Selectable Oscillators
Description
ROHS3Compliant Enable/Disable Crystal e4 Pin Configurable Oscillator -40C~85C 1.8V 2.5V 3.3V 157mA 0.197Lx0.126W 5.00mmx3.20mm
PDF
/
Buying Options
Total Price: USD $37.09
Unit Price: USD $37.086799
≥1 USD $37.086799
≥200 USD $14.797696
≥500 USD $14.304046
≥1000 USD $14.059846
Inventory: 1146
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 0.052 1.33mm
Technical
Frequency - Output 1 100MHz 156.25MHz
Current - Supply (Max) 157mA
Base Resonator Crystal
Function Enable/Disable
Output LVDS
Frequency Stability ±20ppm
Voltage - Supply 1.8V 2.5V 3.3V
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Type XO (Standard)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Series Ultra? Si564
Packaging Strip
Operating Temperature -40°C~85°C
Physical
Package / Case 8-SMD, No Lead
Supply Chain
Factory Lead Time 6 Weeks
