546AAA001008BAG
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Pin Configurable/Selectable Oscillators
Description
ROHS3Compliant Enable/Disable Crystal e4 oscillating selection -40C~85C 2.5V 3.3V 153mA 0.197Lx0.126W 5.00mmx3.20mm
PDF
/
Buying Options
Total Price: USD $29.86
Unit Price: USD $29.859285
≥1 USD $29.859285
≥200 USD $11.914568
≥500 USD $11.516759
≥1000 USD $11.319824
Inventory: 5617
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 0.052 1.33mm
Technical
Frequency - Output 1 147.4545MHz 156.25MHz
Current - Supply (Disable) (Max) 112mA
Current - Supply (Max) 153mA
Base Resonator Crystal
Function Enable/Disable
Output LVPECL
Frequency Stability ±20ppm
Voltage - Supply 2.5V 3.3V
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Type XO (Standard)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
JESD-609 Code e4
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Series Ultra? Si546
Packaging Strip
Operating Temperature -40°C~85°C
Physical
Package / Case 6-SMD, No Lead
