534CB000155DGR
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD, No Lead
Category Crystals, Oscillators, Resonators / Pin Configurable/Selectable Oscillators
Description
RoHS Compliant Enable/Disable Crystal Tape & Reel (TR) oscillating selection -40C~85C 3.3V 88mA 0.276Lx0.197W 7.00mmx5.00mm
PDF
/
Inventory: 4842
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height 0.071 1.80mm
Technical
Frequency - Output 1 20.48MHz 21.2992MHz 22.1184MHz 22.9376MHz
Current - Supply (Disable) (Max) 75mA
Power Supplies 3.3V
Qualification Status Not Qualified
Current - Supply (Max) 88mA
Base Resonator Crystal
Function Enable/Disable
Output CMOS
Frequency Stability ±20ppm
Reach Compliance Code compliant
Supply Voltage 3.3V
Voltage - Supply 3.3V
Subcategory Clock Generators
Type XO (Standard)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.276Lx0.197W 7.00mmx5.00mm
Series Si534
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 8-SMD, No Lead
Supply Chain
Factory Lead Time 6 Weeks
