DSC612NA2A-010JB

Microchip Technology
RoHS
RoHS RoHS compliant
Package 6-VFLGA
Category Crystals, Oscillators, Resonators / Pin Configurable/Selectable Oscillators
Description RoHS Compliant Enable/Disable AEC-Q100; TS 16949 BOTTOM Selectable Oscillator -40C~125C 1.8V 6mA 0.079Lx0.063W 2.00mmx1.60mm
PDF
/
Inventory: 7407
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case 6-VFLGA
Surface Mount YES

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series DSC612
Size / Dimension 0.079Lx0.063W 2.00mmx1.60mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Type XO (Standard)
Voltage - Supply 1.71V~3.63V
Terminal Position BOTTOM
Terminal Form NO LEAD
Supply Voltage 1.8V
Terminal Pitch 0.775mm
Reach Compliance Code compliant
Frequency Stability ±25ppm
Output LVCMOS
JESD-30 Code R-PBGA-N6
Function Enable/Disable
Base Resonator MEMS
Current - Supply (Max) 6mA
Current - Supply (Disable) (Max) 1.5μA
Screening Level AEC-Q100; TS 16949
Frequency - Output 1 24MHz
Frequency - Output 2 32.768kHz

Dimensions

Height 0.035 0.89mm
Length 2mm
Width 1.6mm

Compliance

RoHS Status RoHS Compliant
