DSC2011FM2-E0015
RoHS
RoHS compliant
RoHS compliantPackage 14-VFQFN Exposed Pad
Category Crystals, Oscillators, Resonators / Pin Configurable/Selectable Oscillators
Description
MEMS OSC XO 2.25V-3.6V 14SMD
PDF
/
Inventory: 4327
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 2.4892mm
Length 3.2004mm
Height 0.035 0.90mm
Technical
Frequency - Output 2 20MHz
Frequency - Output 1 20MHz
Max Supply Current 32mA
Current - Supply (Disable) (Max) 23mA
Current - Supply (Max) 32mA Typ
Base Resonator MEMS
Function Enable/Disable
Output CMOS
Frequency Stability ±25ppm
Voltage - Supply 2.25V~3.6V
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type XO (Standard)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series DSC2011
Published 2015
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Package / Case 14-VFQFN Exposed Pad
