DMS-20PC-1-AS-C
RoHS
/
Package /
Category Industrial Automation and Controls / Panel Meters
Description
VOLTMETER 2VDC LED PANEL MOUNT
PDF
/
Inventory: 3132
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Panel
Mounting Type Panel Mount
Weight 0.024lb 10.89g
Technical
Operating Temperature 0°C~60°C
Series DMS-20PC
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Type Voltage (Voltmeter)
Color STANDARD AMBER
HTS Code 8541.40.20.00
Voltage - Supply 5VDC
Number of Functions 1
Termination Style PC Pin
Output Type Reference
Panel Cutout Dimensions Rectangular - 33.93mm x 21.29mm
Forward Current-Max 0.12A
Display Type LED - Amber Characters
Number of Characters Per Row 3.5
Measuring Range ±2VDC
Dimensions
Display Characters - Height 0.370 9.40mm
Display Height 9.4mm
Compliance
RoHS Status RoHS Compliant
