ACA-20PC-4-AC1-RL-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Industrial Automation and Controls / Panel Meters
Description
AMMETER 0-100A LED PANEL MOUNT
PDF
/
Inventory: 1882
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Panel
Mounting Type Panel Mount - Bezel
Weight 0.095lb 43.09g
Technical
Operating Temperature 0°C~60°C
Series ACA-20PC
Feature Built In Current Transformer (Primary)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Current (Ammeter)
Max Operating Temperature 60°C
Min Operating Temperature 0°C
Voltage - Supply 85V~264VAC
Termination Style Screw Terminal
Panel Cutout Dimensions Rectangular - 33.93mm x 21.29mm
Operating Supply Current 30mA
Display Type LED - Red Characters
Input Current 100A
Max Supply Voltage (AC) 264V
Number of Characters Per Row 3.5
Measuring Range 0 ~ 100A
Min Supply Voltage (AC) 85V
Dimensions
Height 22mm
Length 25.4mm
Width 35mm
Display Characters - Height 0.370 9.40mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
