DX1090/YL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / Panel Indicators, Pilot Lights
Description
BULGIN DX1090/YL LED Panel Mount Indicator, Aluminium Bezel, Yellow, 8 mm, 2.1 VDC, 30 mA, 20 mcd, IP66
PDF
/
Buying Options
Total Price: USD $19.05
Unit Price: USD $19.052
≥1 USD $19.052
≥10 USD $14.916
≥100 USD $13.029368
≥500 USD $11.951069
Inventory: 182
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Panel
Number of Pins 2
Panel Cutout Shape Round
Technical
Packaging Bulk
Published 2003
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Type LED
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Number of Functions 1
Ingress Protection IP66
Operating Supply Voltage 2.1V
Panel Cutout Dimensions 0.31 (7.87mm)
Configuration SINGLE
Power Dissipation 105mW
Forward Current 30mA
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Forward Voltage 2.1V
Luminous Intensity 6 mcd
Millicandela Rating 20mcd
Reverse Voltage 5V
Number of LEDs 1
Lamp Color Yellow
Dimensions
Diameter 10.3mm
Length 9mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings Vf (Typ), If (Max)
