Q8P1CXXB24
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / Panel Indicators, Pilot Lights
Description
LED Panel Mount Indicators LED Indicators, 8mm 24VDC, Blue
PDF
/
Buying Options
Total Price: USD $13.29
Unit Price: USD $13.288
≥1 USD $13.288
≥10 USD $10.02584
Inventory: 109
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Surface Mount NO
Mounting Feature PANEL MOUNT
Panel Cutout Shape Round
Technical
Series Q Series
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Solder
Type LED
Voltage - Rated 24V
Additional Feature UL RECOGNIZED
HTS Code 8541.40.20.00
Packing Method BULK
Number of Functions 1
Current Rating 20mA
Termination Style Solder Lug
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Panel Cutout Dimensions 0.31 (7.87mm)
Configuration SINGLE
Viewing Angle 100°
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 1.6 cd
Millicandela Rating 1600mcd
Lens Transparency Diffused
Overall Height 5.1mm
Lamp Color Blue
Compliance
RoHS Status ROHS3 Compliant
Ratings DC
Alternative Model
