Q16P1BZZRYG12E
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Optoelectronics / Panel Indicators, Pilot Lights
Description
INDICATOR 12V 16MM PROM R/Y/G
PDF
/
Buying Options
Total Price: USD $19.9
Unit Price: USD $19.900847
≥1 USD $19.900847
≥10 USD $18.774379
≥100 USD $17.71168
≥500 USD $16.70913
≥1000 USD $15.76333
Inventory: 1159
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Package / Case Metal
Surface Mount NO
Mounting Feature PANEL MOUNT
Panel Cutout Shape Round
Technical
Series Q Series
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Quick Connect
Type LED
Color Green, Red, Yellow
Additional Feature UL RECOGNIZED
HTS Code 8541.40.20.00
Packing Method BULK
Number of Functions 1
Ingress Protection IP67
Termination Style Quick Connect - 0.110 (2.8mm)
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Panel Cutout Dimensions 0.63 (16.00mm)
Configuration COMMON CATHODE, 2 ELEMENTS
Voltage 12V Green 12V Red 12V Yellow
Life (Hours) 100000 hours
Current 20mA Green 20mA Red 20mA Yellow
Viewing Angle 100°
Forward Current 20mA
Lens Style Round with Domed Top
Lens Size 10.00mm Dia
Forward Voltage 12V
Luminous Intensity 50 mcd
Millicandela Rating 50mcd Green, 80mcd Red, 50mcd Yellow
Illumination Color Green, Red, Yellow
Lens Transparency Diffused
Lens Color White
Overall Height 4.75mm
Lamp Color Green, Red, Yellow
Compliance
RoHS Status ROHS3 Compliant
Ratings DC
