NJ-10M-6800
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead, 5 Leads
Category Crystals, Oscillators, Resonators / Oscillators
Description
XTAL OSC OCXO 10.0000MHZ SNWV
PDF
/
Inventory: 7525
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.520 13.20mm
Height 13.208mm
Technical
Max Supply Current 400mA
Base Resonator Crystal
Output Sine Wave
Frequency Stability ±50ppb
Frequency 10MHz
Voltage - Supply 12V
Type OCXO
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 1.000Lx0.870W 25.40mmx22.10mm
Series NJ-10M-6800
Published 2015
Packaging Strip
Operating Temperature -20°C~70°C
Physical
Package / Case 6-SMD, No Lead, 5 Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
