SIT8208AI-32-33S-20.000000Y
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS OSC XO 20.0000MHZ LVCMOS LV
PDF
/
Inventory: 7512
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 4-SMD, No Lead
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Strip
Series SiT8208
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
JESD-609 Code e4
Symmetry-Max 55/45%
Fall Time-Max 2ns
Rise Time-Max 2ns
Operating Frequency 20MHz
Physical Dimension 5.0mm x 3.2mm x 0.75mm
Current - Supply (Max) 33mA
Base Resonator MEMS
Function Standby (Power Down)
Output LVCMOS, LVTTL
Frequency Stability ±25ppm
Frequency 20MHz
Supply Voltage 3.3V
Voltage - Supply 3.3V
Additional Feature STANDBY; ENABLE/DISABLE FUNCTION; TR
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type XO (Standard)
Part Status Active
Pbfree Code yes
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.031 0.80mm
