511FBA000149AAG
RoHS
/
Package 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
XTAL OSC XO 74.175824MHZ LVDS
PDF
/
Inventory: 5941
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.071 1.80mm
Height 1.8034mm
Technical
Max Duty Cycle 52 %
Max Supply Current 23mA
Load Capacitance 15pF
Current - Supply (Disable) (Max) 18mA
Operating Supply Voltage 2.5V
Base Resonator Crystal
Function Enable/Disable
Output LVDS
Frequency Stability ±25ppm
Frequency 74.175824MHz
Voltage - Supply 2.5V
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Type XO (Standard)
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Size / Dimension 0.276Lx0.197W 7.00mmx5.00mm
Series Si511
Published 2004
Packaging Strip
Operating Temperature -40°C~85°C
Physical
Weight 186.029571mg
Number of Pins 6
Package / Case 6-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
