MX555ANU100M000-TR
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
Crystal ROHS3Compliant Enable/Disable Active crystal oscillator 52/48% -40C~85C 0.45ns 95mA
PDF
/
Inventory: 926
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.055 1.40mm
Technical
Symmetry-Max 52/48%
Fall Time-Max 0.45ns
Rise Time-Max 0.45ns
Operating Frequency 100MHz
Physical Dimension 5.0mm x 3.2mm x 1.4mm
Current - Supply (Max) 95mA
Base Resonator Crystal
Function Enable/Disable
Output HCSL
Frequency Stability ±50ppm
Frequency 100MHz
Voltage - Supply 2.375V~3.63V
Terminal Finish Matte Tin (Sn)
Type XO (Standard)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Series MX55
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 6-SMD, No Lead
Mounting Type Surface Mount
