MX553LBC29M7000-TR
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
Crystal RoHS Compliant Enable/Disable Active Oscillator 55/45% -40C~85C 0.5ns 95mA
PDF
/
Inventory: 5429
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 6-SMD, No Lead
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series MX55
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Type XO (Standard)
Terminal Finish Matte Tin (Sn)
Voltage - Supply 2.375V~3.63V
Reach Compliance Code compliant
Frequency 29.7MHz
Frequency Stability ±50ppm
Output LVCMOS
Function Enable/Disable
Base Resonator Crystal
Current - Supply (Max) 95mA
Physical Dimension 5.0mm x 3.2mm x 1.4mm
Operating Frequency 29.7MHz
Rise Time-Max 0.5ns
Fall Time-Max 0.5ns
Symmetry-Max 55/45%
Dimensions
Height Seated (Max) 0.055 1.40mm
Compliance
RoHS Status RoHS Compliant
