DSC6331MI2BA-038.0000
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS ROHS3Compliant Active LVCMOS crystal oscillator 55/45% -40C~85C 2ns 3mA Typ
PDF
/
Inventory: 4934
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 4-SMD, No Lead
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Bag
Series DSC63XX
Size / Dimension 0.079Lx0.063W 2.00mmx1.60mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Type XO (Standard)
Terminal Finish Matte Tin (Sn)
Additional Feature TUBE
Voltage - Supply 1.8V~3.3V
Frequency 38MHz
Frequency Stability ±25ppm
Output LVCMOS
Base Resonator MEMS
Current - Supply (Max) 3mA Typ
Physical Dimension 2.0mm x 1.6mm x 0.89mm
Operating Frequency 38MHz
Rise Time-Max 2ns
Fall Time-Max 2ns
Symmetry-Max 55/45%
Spread Spectrum Bandwidth ±0.50% Center Spread
Dimensions
Height Seated (Max) 0.035 0.89mm
Compliance
RoHS Status ROHS3 Compliant
