DSC6101ML3B-016.6666T
RoHS
RoHS compliant
RoHS compliantPackage 4-VFLGA
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS RoHS Compliant Enable/Disable Active Oscillator 55/45% -40C~105C 2ns 3mA Typ
PDF
/
Inventory: 6637
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q100
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.035 0.89mm
Technical
Symmetry-Max 55/45%
Fall Time-Max 2ns
Rise Time-Max 2ns
Operating Frequency 16.6666MHz
Physical Dimension 2.0mm x 1.6mm x 0.89mm
Current - Supply (Max) 3mA Typ
Base Resonator MEMS
Function Enable/Disable
Output CMOS
Frequency Stability ±20ppm
Frequency 16.6666MHz
Reach Compliance Code compliant
Voltage - Supply 1.71V~3.63V
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Type XO (Standard)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Size / Dimension 0.079Lx0.063W 2.00mmx1.60mm
Series DSC61XXB
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Surface Mount YES
Package / Case 4-VFLGA
Mounting Type Surface Mount
