DSC6101HL3B-027.0000
RoHS
RoHS compliant
RoHS compliantPackage 4-VFLGA
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS RoHS Compliant Enable/Disable Active crystal oscillator 55/45% -40C~105C 2ns 3mA Typ
PDF
/
Buying Options
Total Price: USD $1.17
Unit Price: USD $1.167035
≥1 USD $1.167035
≥10 USD $1.100972
≥100 USD $1.038654
≥500 USD $0.979865
≥1000 USD $0.924405
Inventory: 1174
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q100
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.035 0.89mm
Technical
Symmetry-Max 55/45%
Fall Time-Max 2ns
Rise Time-Max 2ns
Operating Frequency 27MHz
Physical Dimension 1.6mm x 1.2mm x 0.89mm
Current - Supply (Max) 3mA Typ
Base Resonator MEMS
Function Enable/Disable
Output CMOS
Frequency Stability ±20ppm
Frequency 27MHz
Reach Compliance Code compliant
Voltage - Supply 1.8V~3.3V
Terminal Finish Matte Tin (Sn)
Type XO (Standard)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.063Lx0.047W 1.60mmx1.20mm
Series DSC61XXB
Packaging Bag
Operating Temperature -40°C~105°C
Physical
Surface Mount YES
Package / Case 4-VFLGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
