DSC6013HI2A-003.6864 image
Favorite
DSC6013HI2A-003.6864 image
Favorite

DSC6013HI2A-003.6864

Microchip Technology
RoHS
RoHS RoHS compliant
Package 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description MEMS OSC XO 3.6864MHZ CMOS SMD
PDF
/
Inventory: 5034
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings AEC-Q100
RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.035 0.89mm

Technical

Symmetry-Max 55/45%
Fall Time-Max 3.5ns
Rise Time-Max 3.5ns
Operating Frequency 3.6864MHz
Physical Dimension 1.6mm x 1.2mm x 0.89mm
Current - Supply (Max) 1.3mA Typ
Base Resonator MEMS
Function Standby (Power Down)
Output CMOS
Frequency Stability ±25ppm
Frequency 3.6864MHz
Voltage - Supply 1.8V~3.3V
Type XO (Standard)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.063Lx0.047W 1.60mmx1.20mm
Series DSC60XX
Packaging Bag
Operating Temperature -40°C~85°C

Physical

Surface Mount YES
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
