DSC6001HI2A-024.0000T
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS ROHS3Compliant Enable/Disable Active Oscillator 55/45% -40C~85C 2ns 1.3mA Typ
PDF
/
Inventory: 1365
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q100
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.035 0.89mm
Technical
Symmetry-Max 55/45%
Fall Time-Max 2ns
Rise Time-Max 2ns
Operating Frequency 24MHz
Physical Dimension 1.6mm x 1.2mm x 0.89mm
Current - Supply (Max) 1.3mA Typ
Base Resonator MEMS
Function Enable/Disable
Output CMOS
Frequency Stability ±25ppm
Frequency 24MHz
Voltage - Supply 1.8V~3.3V
Type XO (Standard)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.063Lx0.047W 1.60mmx1.20mm
Series DSC60XX
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
