DSC1122BL2-018.4320
RoHS
RoHS compliant
RoHS compliantPackage 6-VDFN
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS RoHS Compliant Enable/Disable Active Oscillator 52/48% -40C~105C ±25ppm 58mA
PDF
/
Inventory: 2960
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 6-VDFN
Surface Mount YES
Technical
Operating Temperature -40°C~105°C
Packaging Tube
Series DSC1122
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type XO (Standard)
Voltage - Supply 2.25V~3.6V
Reach Compliance Code compliant
Frequency 18.432MHz
Output LVPECL
Function Enable/Disable
Base Resonator MEMS
Current - Supply (Max) 58mA
Physical Dimension 5.0mm x 3.2mm x 0.85mm
Operating Frequency 18.432MHz
Symmetry-Max 52/48%
Current - Supply (Disable) (Max) 22mA
Absolute Pull Range (APR) ±25ppm
Dimensions
Height Seated (Max) 0.035 0.90mm
Compliance
RoHS Status RoHS Compliant
