DSC1122BE2-018.4320T
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
Standard Clock Oscillators 5032 pkg -20-70C 25ppm 018.4320MHz
PDF
/
Inventory: 4634
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.2004mm
Length 5.0038mm
Height Seated (Max) 0.035 0.90mm
Height 889μm
Technical
Max Duty Cycle 52 %
Max Supply Current 58mA
Load Capacitance 0F
Min Supply Voltage 2.25V
Max Supply Voltage 3.6V
Current - Supply (Disable) (Max) 22mA
Current - Supply (Max) 58mA
Base Resonator MEMS
Function Enable/Disable
Output LVPECL
Frequency Stability ±25ppm
Frequency 18.432MHz
Voltage - Supply 2.25V~3.6V
Min Operating Temperature -20°C
Max Operating Temperature 70°C
Type XO (Standard)
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Series DSC1122
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C
Physical
Package / Case 6-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
