DSC1121CM2-024.0000
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS ROHS3Compliant Enable/Disable Active Oscillator 125C 35mA 0.035 0.90mm 24MHz
PDF
/
Inventory: 6143
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q100
RoHS Status ROHS3 Compliant
Dimensions
Width 2.4892mm
Length 3.2004mm
Height Seated (Max) 0.035 0.90mm
Height 889μm
Technical
Max Supply Current 35mA
Current - Supply (Disable) (Max) 22mA
Current - Supply (Max) 35mA
Base Resonator MEMS
Function Enable/Disable
Output CMOS
Frequency Stability ±25ppm
Frequency 24MHz
Voltage - Supply 2.25V~3.6V
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type XO (Standard)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series DSC1121
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Package / Case 6-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
