DSC1121BE5-024.0000
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS RoHS Compliant Enable/Disable Active crystal oscillator 55/45% -20C~70C 2ns 35mA
PDF
/
Inventory: 8945
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.035 0.90mm
Technical
Current - Supply (Disable) (Max) 22mA
Symmetry-Max 55/45%
Fall Time-Max 2ns
Rise Time-Max 2ns
Operating Frequency 24MHz
Physical Dimension 5.0mm x 3.2mm x 0.85mm
Current - Supply (Max) 35mA
Base Resonator MEMS
Function Enable/Disable
Output CMOS
Frequency Stability ±10ppm
Frequency 24MHz
Reach Compliance Code compliant
Voltage - Supply 2.25V~3.6V
Terminal Finish Matte Tin (Sn)
Type XO (Standard)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Series DSC1121
Packaging Tube
Operating Temperature -20°C~70°C
Physical
Surface Mount YES
Package / Case 6-SMD, No Lead
Mounting Type Surface Mount
