DSC1121AL5-022.5792

Microchip Technology
RoHS
RoHS RoHS compliant
Package 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description MEMS ROHS3Compliant Enable/Disable Active Oscillator -40C~105C 22mA 0.035 0.90mm 22.5792MHz
PDF
/
Inventory: 3781
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.035 0.90mm

Technical

Current - Supply (Max) 22mA
Base Resonator MEMS
Function Enable/Disable
Output CMOS
Frequency Stability ±10ppm
Frequency 22.5792MHz
Voltage - Supply 2.25V~3.6V
Terminal Finish Matte Tin (Sn)
Type XO (Standard)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.276Lx0.197W 7.00mmx5.00mm
Series DSC1121
Packaging Tube
Operating Temperature -40°C~105°C

Physical

Package / Case 6-SMD, No Lead
Mounting Type Surface Mount
