DSC1104CI5-100.0000
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS OSC XO 100.0000MHZ HCSL SMD
PDF
/
Inventory: 5315
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 2.4892mm
Length 3.2004mm
Height Seated (Max) 0.035 0.90mm
Height 889μm
Technical
Max Supply Current 42mA
Current - Supply (Disable) (Max) 95μA
Current - Supply (Max) 42mA
Base Resonator MEMS
Function Standby (Power Down)
Output HCSL
Frequency Stability ±10ppm
Frequency 100MHz
Voltage - Supply 2.25V~3.6V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type XO (Standard)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series DSC1104
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 6-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
