DSC1103CI1-125.0000T
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
OSC MEMS 125.000MHZ LVDS SMD
PDF
/
Buying Options
Total Price: USD $3.61
Unit Price: USD $3.608
≥1 USD $3.608
≥10 USD $3.42848
≥100 USD $3.247728
Inventory: 2269
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, No Lead
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series DSC1103
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type XO (Standard)
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature STANDBY; ENABLE/DISABLE FUNCTION; DIFFERENTIAL OUTPUT; LVPECL HCSL O/P ALSO AVAILABLE; TAPE AND REEL
Voltage - Supply 2.25V~3.63V
Frequency 125MHz
Frequency Stability ±50ppm
Output LVDS
Function Standby (Power Down)
Base Resonator MEMS
Physical Dimension 3.2mm x 2.5mm x 0.85mm
Operating Frequency 125MHz
Symmetry-Max 52/48%
Current - Supply (Disable) (Max) 95μA
Max Supply Current 32mA
Dimensions
Height 889μm
Height Seated (Max) 0.035 0.90mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q100
